Brand Name : | Sea radium laser |
Model Number : | HL-F-20W/30W |
Certification : | CE,CCC |
Price : | negotiable |
Supply Ability : | 1500 units per month |
Delivery Time : | 5-8 working days |
Desktop Laser Marking Machine With HD Display Screen Small Size
Marking Machine
Characteristics of desktop Laser Marking Machine:
Desktop laser marking machine, light and agile, easy to operate;
It has small size, good beam quality, maintenance-free, long service life, high electro-optic conversion efficiency, etc.
● The compact desktop design;
● Delicate marking with superior laser beam;
● Fast speed laser marking;
● Stable output power, high reliability, 24 hours continuous
operation ;
● Advaced marking software;
Product details
Technical parameter:
Item | Item parameter |
Laser frequency | 10W |
Laser wavelength | 1064nm |
Repetition rate | 20-80 KHZ |
Fundamental mode Gaussian beam | < 2 |
Marking range | 100*100mm(range optional) |
Engraving depth | 0.4 mm or less |
Engraving line speed | ≤10000mm/s |
Minimum line width | The 0.01 mm |
Minimum character | The 0.15 mm |
repeatability | ±0.002 |
Power supply | 220V/50Hz |
Complete power consumption | 500W |
Overall dimension | 700mmx200mmx490mm |
Machine weight | About 40KG |
Operating system | Windows 7 32-bit |
Cooling mode | Built-in air cooling |
Interface type | Standard USB |
File format | PLT EPS AI DXF WMF |
Laser type | Pulsed fiber laser |
Application field:
Widely used in any metal materials, electroplated plastics, industrial plastics, spraying materials, some glass, ceramic products and so on
It can also help customers to engraves personal gifts. (For example, engraved names on coke bottles or personal Logo,ect)
Sample Display(Part Only)
Profession and Honor
About this product,we also support customized services,If you would
like to know further product information and requirements, please
contact us online or send E-mail to us.Thank you for your time!
![]() |
